Dimensions
Width: 17cm, Height: 4.5cm,
Depth: 2.5cm

Weight
Gr. 350 ca.

Displays
Fare counter:
5 or 6 digits - Red High Luminosity Led
Extra counter:
4 digits Red Light-Luminosity Led
Illuminated Front text
Tariff Index:
1 digit Red High Luminosity Led

Power Supply
From 8.5 to 16 Volts

Temperature
From -15 to 70°C

Relative Humidity
95%

Mechanical Strength
3g

Distance Unit
From 10 cm to 6553 metres
Step 10 cm

Waiting Time Unit
From 0.1 sec. to 6553
Step 0.1 sec.

Totaliser Mode
Statistical memory 7 & 7

Tariff Structure
32 Smart and fully independent Tariffs
+4 Night Tariffs
+4 Holiday Tariffs
+4 Autofare Tariffs
+4 Autodistance Tariffs

Tariff Choice Manual
Automatic at pre-programmed:
Distance(s)
Time(s)
Date(s)
Fare(s)
Amount(s)

Tariff Programme Change
Memory Key
By Programmer

Peripheral Connections
Printer
Infrared Passenger Sensor
Mobile Data Terminal

Communications Ports
Internal COM1
RS232 +/- 12 Volts STD

Operative Firmware
Firmware is on Reprogrammable Flash Eprom upgradable by reprogramming on board (Not OTP Chip)

Transducer
Mechanical Hall Effect or Internal adapter for electronic speedometer up to 100.000 I/km

Power Outputs
1 Roof Light 25 Watts
4 Programmable power outputs 5 Watts
